| VIRGIN PTFE Properties | Unit | Result |
| Apparent Density | g/cm3 | 2.10~2.25 |
| Tensile Strength | Mpa | ﹥25 |
| Ultimate Elongation | % | ﹥200 |
| Working Temperature | ℃ | -180~260 |
| Melting Point | ℃ | 327 |
| Produce Max. temperature | ℃ | 385 |
| Hardness Rockwell | M65 |
| Graphite (Filled PTFE) | Glass Fiber Filled PTFE |
| Good thermal conductivity | |
| Chemically inert | Oxidation and acid resistance |
| Low friction | Dimensional stability |
| Minimum wear to mating surface |
| Carbon Fiber (Filled PTFE) | Bronze (Filled PTFE) |
| Extremely good chemical resistance | Improved comprehensive strength and hardness |
| virtually all media | |
| Wide temperature range(-260℃~+260℃) | High thermal conductivity |
| Good sliding properties | Low creep, wear and friction |
| Improved dimensional stability |
Goods for high load unlubricated bearings |
| Improved creep resistance | |
| Very good electrical insulation properties |
